WP 150 wide-span cable ladder, height = 150 mm

Wide-span cable ladder, additional transverse rigidity due to welded rungs, rungs made of profile rail perforated. Electrical conductivity tested according to DIN EN 61537.

Welded construction.

data sheet

Do not walk upon!

Hot-dip galvanized, according to BS 729 (DIN EN ISO 1461)

	height	width	length	weight
WP15-20-HDG	150 mm	200 mm	6000 mm	42,42 kg
WP15-30-HDG	150 mm	300 mm	6000 mm	42,84 kg
WP15-40-HDG	150 mm	400 mm	6000 mm	45,21 kg
WP15-45-HDG	150 mm	450 mm	6000 mm	46,40 kg
WP15-50-HDG	150 mm	500 mm	6000 mm	47,60 kg
WP15-60-HDG	150 mm	600 mm	6000 mm	49,99 kg
WP15-70-HDG	150 mm	700 mm	6000 mm	52,38 kg
WP15-75-HDG	150 mm	750 mm	6000 mm	53,58 kg
WP15-80-HDG	150 mm	800 mm	6000 mm	54,78 kg
WP15-90-HDG	150 mm	900 mm	6000 mm	57,17 kg
WP15-100-HDG	150 mm	1000 mm	6000 mm	59,56 kg

Stainless steel, according to ASTM 304 / BS 304 S 3

	height	width	length	weight
WP15-20-304	150 mm	200 mm	6000 mm	42,42 kg
WP15-30-304	150 mm	300 mm	6000 mm	42,84 kg
WP15-40-304	150 mm	400 mm	6000 mm	45,21 kg
WP15-45-304	150 mm	450 mm	6000 mm	46,40 kg
WP15-50-304	150 mm	500 mm	6000 mm	47,60 kg
WP15-60-304	150 mm	600 mm	6000 mm	49,99 kg
WP15-70-304	150 mm	700 mm	6000 mm	52,38 kg
WP15-75-304	150 mm	750 mm	6000 mm	53,58 kg
WP15-80-304	150 mm	800 mm	6000 mm	54,78 kg
WP15-90-304	150 mm	900 mm	6000 mm	57,17 kg
WP15-100-304	150 mm	1000 mm	6000 mm	59,56 kg

Stainless steel, according to ASTM 31 Ti / AISI 316 L, BS 320S17 / BS 316S11

	height	width	length	weight
WP15-20-316	150 mm	200 mm	6000 mm	42,42 kg
WP15-30-316	150 mm	300 mm	6000 mm	42,84 kg
WP15-40-316	150 mm	400 mm	6000 mm	45,21 kg
WP15-45-316	150 mm	450 mm	6000 mm	46,40 kg
WP15-50-316	150 mm	500 mm	6000 mm	47,60 kg
WP15-60-316	150 mm	600 mm	6000 mm	49,99 kg
WP15-70-316	150 mm	700 mm	6000 mm	52,38 kg
WP15-75-316	150 mm	750 mm	6000 mm	53,58 kg
WP15-80-316	150 mm	800 mm	6000 mm	54,78 kg
WP15-90-316	150 mm	900 mm	6000 mm	57,17 kg
WP15-100-316	150 mm	1000 mm	6000 mm	59,56 kg
